GRILLO CLIMBER 10 AWD 27
Grillo Climber 10 AWD 27 is a truly unique hydrostatic brush-cutter. The permanent 4WD system combined with the 27 HP powerful engine (22 HP net power) offer brilliant performances on severe slopes and low-adherence grounds. Remarkably efficient on high grass and up to 2,5 cm diametre shrubs, this machine is ideal for both agricultural and professional use. Its compact dimension has been designed to boost its performance on slopes and the Kanzaki hydrostatic transmission with differential lock on the rear wheels allow the operator to work with maximum safety, reliability and unmatched stability under any working condition.
Engine: Briggs & Stratton Series 8270 Commercial, Start electric, with 12 V battery, Supply fuel, Displacement 724 cc, 2 Cylinders, Power 22 HP (16.2 kW), Air cooled
Dry air filter with interchangeable filter cartridges
Fuel tank capacity: 13 L
Gearbox: 4-wheel-drive hydrostatic transmission.
Clutch: Electromagnetic clutch with P.T.O and blade brake.
Cutter deck: side and rear discharge
Cutting configuration: 1 rotating blade
Cutting width: 98 cm
Cutting height: From 35 mm to 135 mm with continuous adjustment.
Peripheral blade speed: 87 m/1″
Differential locking: On the rear axle, with pedal engagement.
Front tyres: 16×6.50-8 tractor. With anti-puncture treatment as standard feature.
Rear tyres: 20×10.00-8 TRACTOR
Speed: Continuously variable from 0 to 9 km/h + reverse speed from 0 to 8 km/h
Inner turning radius: 70 cm
Seat: With weight-adjustable suspension, equipped with roll-bar
Parking brake: On the rear wheels with lever engagement.
Mowing capacity per hour (indicative): 7500 m^2/h
Length: 206 cm
Width: 108 cm
Height: 118,5 cm
Weight: 383 kg
